10L to'planadigan mog'or mashinasini yig'ish mashinasi

Model:KGB70A

KGB70A - Max 15 litrli shisha zarbasi uchun maksimal 10 ta ko'prikli mog'orlangan mashinasozlik mashinasidir. Suvdagi etakchi shisha vositachiligi sifatida biz mijozning talablariga javob beradigan shaxsiy echimlarni taklif qilamiz. Mashina nafaqat suv idishlari, pestitsid konteynerlari va kunlik kimyoviy qadoqlash ishlab chiqarish, balki kichik, ammo maxsus shakllar uchun ham. Ushbu mashina turli xil ehtiyojlarga javob beradi.

Ovoz balandligi: 20LOg'irligi: 7.8T

So'rov yuborish

Mahsulot tavsifi Specification Application

KGB70A 10L to'plangan shakllantirish mashinasi - bu mahkam ochilgan va yopilish Model, bu ikki marta tortadigan novdani sinxron qisish mexanizmini, moyni qabul qiladi silindrni to'g'ridan-to'g'ri blokirovka qilish mog'or, akkumulyator tsilindrli bosh dirise. GMSRALIK SERVO tizimini boshqarish, tezkor javob tezligi va energiya tejash.
Ushbu maxsus dizayn shaklini ishlab chiqarish uchun ko'proq to'plam, mumkin Shakl va qalinlikni batafsil boshqarish.

Xususiyatlar va afzalliklar

Ushbu model belgilangan ochilish va yopish shaklidir, dublli tog 'sinxron plyonkali kino mexanizmi yordamida, yog' silindrining to'g'ridan-to'g'ri bosimi qolipni qulflaydi
● Saqlash tsilindrining o'lishi boshi
● Maksimal hajmi 20L
● suv idishlari, pestitsid konteynerlari va kundalik kimyoviy qadoqlash va boshqalarga mos keladi.
● farqlovchi xususiyati shundaki, u ta'sirli harakatlar va yuqori energiya samaradorligiga erishish uchun gidravlika tizimi tomonidan boshqariladi.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
